Stainless steel handrail cable is a railing system that uses stainless steel as the main component. It consists of stainless steel cables, support columns and fixing accessories. It not only provides structural support and safety protection, but is also popular for its modern and simple appearance. Stainless steel cable railings are widely used in residential, commercial buildings, public facilities and landscape design. It has become a model of the combination of modern architectural aesthetics and safety performance.
Seaside balcony application
decks with cable railing
stainless cable railing
Wanzhi Steel provides 304 or 316 cable materials, 36″ or 42″Railing Height, 33.7/38.1/42.4/48.3/50.8mm round tube size for you to choose from. We also have railing styles made of aluminum, brass, WPC, iron, galvanized steel, and cast iron. All sizes are customizable.
Stainless steel handrail cable Specification
| Item | Stainless steel handrail cable |
| Project Solution Capability | graphic design, 3D model design, total solution for projects, Cross Categories Consolidation |
| Position | Bridge Railings / Handrails, Deck Railings / Porch Railings / Stair Railings /Glass balustrade |
| Installation | DIY Install |
| Material | 304, 316 Stainless steel or zinc alloy |
| OEM&ODM | Available |
| Wire size | 3-40mm(1/8 inch-3/8 inch) |
| Surface finish | Stain Brush Finish (hairline Finish) |
| Railing height | 850-1200mm for glass (36″ or 42″) |
| Application | Deck,balcony,stair |
| Color | Black or Nickel White or Brushed or Mirror |
| Mode of transport | UPS / Fed EX / by sea LCL. FCL / by truck / by air |
Note:
Cable diameter: Common ones are 1/8 inch (about 3.2 mm), 3/16 inch (about 4.8 mm), 1/4 inch (about 6.4 mm), 5/16 inch (about 7.94mm), 3/8 inch (about 9.53mm)
Support structure: It can be wood, metal, or other materials. Stainless steel is the most commonly used material because it matches the cable material and has a consistent visual effect.
Installation spacing: The spacing between cables is usually 3 inches (about 7.6 cm) or less to prevent children or pets from passing through.
decking wire balustrade digram
Stainless Railing specifications
| Item | Stainless Railing (Support structure) |
| Cable railing shape | Round /square/D type |
| Round railing | 38.1mm、42.4mm、50.8mm、60.3mm |
| Square railing | 40*40 mm 50*50 |
| Pipe Thickness | 1.2mm to 2.0mm |
| For glass thickness | 10-16mm |
| Material | 304、316、Aluminum |
| Surface | Black/white/brushed/mirror/grey.etc |
| Install | Top mounted、Side mounted |
| If you need customization, welcome to contact us! | |
Advantages
Aesthetics: Simple design, transparent appearance, providing a sense of openness and transparency.
Durability: Stainless steel has excellent corrosion resistance and rust resistance, and maintains a long life in various climates.
High strength: Stainless steel cable railings can withstand large tension and pressure, ensuring stable safety protection.
Flexibility: DIY installation supports flexible combinations of support columns and cables, regardless of whether it is a complex space requirement.
Low maintenance: Stainless steel handrail cable requires almost no maintenance, only regular cleaning is required.
Seaside Deck Handrail
Uses
Residential: Used for balconies, stairs, terraces, and courtyards, providing safety protection without blocking the view.
Business buildings: Suitable for indoor and outdoor railings in office buildings, hotels, restaurants, libraries, and other places to enhance the overall aesthetics.
Outdoor public facilities: Public places such as parks, squares, bridges, etc., provide safety protection without affecting the landscape.
Ships and docks: Due to their corrosion resistance, stainless steel cable railings are also commonly used for guardrails on decks and docks.
| Cable diameter | Applicable scenarios | Applications |
| 1/8″ | The most popular diameters for residential railings | Horizontal railing, vertical railing use |
| 3/16″, 1/4″ | The most common sizes for commercial railings | High security residential railing, commercial railing |
| 5/16″, 3/8″ | Common sizes for gravity installations | Anywhere a visually rugged appearance is required |
diy cable railings
Indoor library use
ss wire balustrade
Recommended Metal Frame Styles
Double End Post Construction
Use 2″x1″x.120″ or 3″x1″x.120″ structural steel posts with stainless steel spacers.
Use 2″x1″ or 3″x1″ top and bottom rails and intermediate posts (if applicable).
2″X 2″X 1/4″ Wall Structural Steel End Post Construction
Use 2″x1″ top and bottom cross members (if applicable).
Even if the end posts are 2″x2″x.250″, the intermediate posts can be 2″x1″x.120″ to minimize the bulkiness of the frame.
Tube and Round Steel Pipe Posts
Use 1-1/4″, 1-1/2″ or 2″ standard pipe.
You need at least Schedule 80 pipes for your end posts.
Column installation diagram
Coated Cables
PVC coatings have UV inhibitors, and if exposed to sunlight for a long time, they will gradually fade, harden, crack, and peel, which is not conducive to cleaning. Therefore, for outdoor environments, stainless steel cables are smooth to the touch, will not wear, and can be used in outdoor environments without coating.
If you use it indoors and have a limited budget, you can consider coated cables.
Related items
| Related items | ||
| 90° connector | End cap | Connector |
| Cover | Holder Bracket | Cable Railing Door |
| Hydraulic Style | Wire rope | Blot |
Column connection screw
Stainless steel accessories set
Black stainless steel square tube column
Price
1. Material cost: The price of stainless steel cable is about $1-3 per foot, depending on the diameter and material.
2. Support Structure: Stainless steel posts cost about $50-200 each, depending on the material and design.
3. Installation Cost: Installation costs are usually calculated per linear foot, about $20-50/foot.
4. Total Cost: For a moderately complex residential project, the total cost of stainless steel cable railings may range from $50-150 per linear foot.
If you need help, we will design a plan for you based on your application or drawings and calculate the exact price.
Slope installation diagram
Purchase Tips
For cable railings, we recommend 1×19 structure, 316 stainless steel strand (cable), because you need the strongest possible cable with low elongation. 7×7 or 7×19 structure is less rigid than 1×19, and has high elongation, and the breaking strength is also lower than 1×19 structure.
Stainless Steel Handrail Cable Package
This product is packed in transparent plastic bags or plastic film + paper boxes and shipped as a set. Shipping by sea or air.
If you have some accessories, you can also choose to ship a single item.
s-l960
Stainless steel screw packaging
steel rope handrail package
Why choose Wanzhi Steel?
1) Almost products have in stock, delivery time 7-15 days.
2) Stainless steel 316/2205 grade can be used in a severe environment.
3) Mature and diverse product series to meet your design and needs. And we can also custom made for your design.
4) Our QC checks the surface, material, size, and packing of every item to promise the goods are perfect for your hand.
5) Europe, Asia, South America, Africa, and Australia are our main markets.
We specialize in the production of railing systems and fence panels, with a monthly output of 1,600 tons.
We have been established for 14 years and have rich export experience, countless cooperation cases, and a focus on quality manufacturing.
Which are worthy of your trust and choice~
