Stainless Steel Chicken Wire is a mesh material made of woven stainless steel wires in silver-white color and hexagonal opening, which is known for its corrosion resistance, high strength and long service life for use in agriculture, construction, horticulture, and other fields. Its name derives from the original use of chicken coops for poultry farming, but today its applications extend far beyond that. Wanzhi Steel stocks a large quantity of Stainless Steel Chicken Wire Mesh made of 304, 316 in 1mm, 2mm, 3mm, and other sizes, if you want to know more about it, please feel free to contact us.

Stainless Steel Chicken Wire Specification

Item	Stainless Steel Chicken Wire
Hole Shape	Hexagonal
Processing Service	Bending, Welding, Decoiling, Cutting, Punching
Place of Origin	Hebei, China
Delivery Time	15-21 days
Material	201, 204, 304, 304l, 316, 316l, 430 Stainless wire
Wire Gauge	BWG10-22(Wire diameter:0.3-1.0mm)
Roll Length	10-500m
Roll Height/Width	0.3-2.5m
Mesh Size	3/8″,1/2″,3/4″,5/8″,1″,2″, 3″, 4″, etc.
Surface Treatment	Untreated, or galvanized, PVC/PU/vinyl coated, powder coated(Color: Customized )
Payment	TT 30% in advance, 70% before shipment
MOQ	200 rolls
Shipment	Sea freight, land freight

Advantages

1. High strength: able to withstand large external forces and not easy to deform or fracture. 06Cr19Ni10 (new grade) stainless steel tensile strength greater than or equal to 515MPa.

2. High temperature resistance: high temperature environment to maintain stability, 304 high temperature resistance 850 ° – 900 ° C, 310 high temperature resistance 1050 ° – 1150 ° C.

Recommended wire gauge for different mesh sizes

Positive Twisted Chicken Hexagonal Wire Mesh

Mesh hole size		Wire Gauge (BWG)
Inche	millimeter	/
3/8”	10 mm	27,26,25,24,23,22,21
1/2”	13 mm	25,24,23,22,21,20
5/8	16 mm	27,26,25,24,23,22
3/4”	20 mm	25,24,23,22,21,20,19
1”	25 mm	25,24,23,22,21,20,19,18
1 1/4”	32 mm	22,21,20,19,18
1-1/2”	40 mm	22,21,20,19,18,17
2”	50 mm	22,21,20,19,18,17,16,15,14
3”	75mm	21,20,19,18,17,16,15,14
4”	100mm	17,16,15,14



Reverse Twisted Chicken Hexagonal Wire Mesh

Mesh hole size		Wire Gauge	Reinforcement
Inch	mm		Width(ft)	Strand
1″	25mm	22,21,20,18	2’	1
1-1/4″	32mm	22,21,20,18	3’	2
1-1/2″	40mm	20,19,18	4’	3
2″	50mm	20,19,18	5’	4
3″	75mm	20,19,18	6’	5

Chemical composition

Stainless steel chicken wire mesh is usually made of 304 or 316 stainless steel. The chemical composition of these two types of stainless steel is as follows:

304 stainless steel: contains 18% chromium (Cr) and 8% nickel (Ni), as well as small amounts of carbon (C), manganese (Mn), silicon (Si), and phosphorus (P). 304 stainless steel has good corrosion resistance and mechanical properties, suitable for most environments.

316 stainless steel: 2% molybdenum (Mo) is added on the basis of 304, which further improves the corrosion resistance, especially in the chloride environment. Extremely resistant to pitting, it is commonly used in marine environments or in the chemical industry.

Stainless steel chicken wire mesh application areas

Home use: pet enclosure, storage net, craft ornaments.

Livestock and poultry cages: chicken cages, rabbit cages, squirrel cages, duck cages, goose cages, etc.

Fruit and vegetable protection nets: prevent pests and small animals from infesting fruits and vegetables, while safeguarding ventilation and light.

Fishing nets: fishing nets, fishing gear, etc., corrosion-resistant, wear-resistant, and able to adapt to the seawater environment.

Aquaculture: shrimp, crab, shellfish, and other aquatic products breeding tanks, breeding cages

Chemical industry: filtration in reactor, stacking containers for chemicals.

Types

Stainless steel chicken wire mesh can be divided into the following categories according to different weaving methods and specifications:

According to the weaving method

– Plain weave: the most common weave with uniform mesh and high strength.

– Twill weave: better flexibility and tensile strength, suitable for complex shape installation.

According to the surface treatment

– Bright surface: smooth surface, beautiful and easy to clean.

– Galvanized surface: further improve corrosion resistance, suitable for extreme environment.

-Plastic coated surface: wrapped by PVC, PU, PE or vinyl, the highest level of protection for metal wire.

Production process

1. Raw material preparation: choose high quality stainless steel wire and make sure its chemical composition and physical properties meet the standard.

2. Wire drawing: Stainless steel billet or stainless steel Wire rod is drawn into steel wire of required diameter by wire drawing machine.

3. Weaving: adopt automatic weaving machine to weave the steel wire into a mesh structure with an even and flat grid.

4. Surface treatment: optional, according to customer requirements, the mesh surface is brightly treated, galvanized. Or further plasticized.

5. Cutting: Cut the woven wire mesh rolls into the required sizes with the weight of 10kg, 20kg, 50kg, or 20m/roll, 100m/roll.

6. Packing: Packed in rolls with Plastic Film, Waterproof Woven Fabric, Wooden pallets, and so on.

Free On Board (FOB) price

The price of stainless steel chicken wire mesh is related to its raw material cost, specification, surface treatment and market supply and demand.

FOB (Free On Board) price for reference (regular size):

304 Stainless Steel Chicken Wire Mesh cost

– Mesh size: 1/2 inch, wire diameter: 0.8mm, price about $15-$20/roll (about 30 meters per roll).

– Mesh size: 1 inch, wire diameter: 1.2mm, price is about $25-$30/roll.

316 Stainless Steel Chicken Wire Mesh cost

– Mesh size: 1/2 inch, wire diameter: 0.8mm, price is about $20-$25/roll.

– Mesh size: 1 inch, wire diameter: 1.2mm, price is about $30-$35/roll.



For actual price, please send your wire diameter, mesh hole, roll length and height to our professional technicians, we will calculate the quotation for you anytime.

Advantages of our factory

As a factory specializing in stainless steel chicken wire mesh, we have significant advantages in the following aspects:

1. Monthly production: the monthly production capacity reaches 10,000 tons, which can meet the demand of large-volume orders and ensure timely delivery.

2. Mature technology: We have advanced production equipment and a team of 200+ people in technology, factory, quality inspection, office and delivery to ensure stable and reliable product quality.

3. Global customer coverage: Our products are exported to Europe, North America, Southeast Asia, North Africa, Central Asia, the Middle East and other regions, trusted by customers.

4. Factory production line: we have several automatic production lines, which can efficiently complete the whole process of production from raw materials to finished products.

5. Customized service: We support customized stainless steel chicken wire mesh with different specifications, sizes, and surface treatments according to customers’ needs.

6. Quality control: We strictly implement ISO9001 quality management system to ensure that each batch of products meets international standards.



With advanced technology, efficient production capacity, our factory is committed to providing customers with high-quality products and services. If you have any requirements, please feel free to contact us, we will be happy to serve you.
