Black chain link fence has excellent corrosion resistance, good impact resistance, and durability, not only has a beautiful appearance but also plays a safe isolation role, it is the preferred choice for everyone to buy fence, Wanzhi Steel is a specialized supplier of black chain link fence, we accept customization of wire diameter, aperture, length, height, for bulk purchase, provide factory price, you are welcome to Chat With Us for details.

8ft 9 Gauge Galvanized Diamond Fence

PVC Black Coated Chain Link Woven Mesh

Black Vinyl Chain Link Fence

Specification

Item	Black Chain Link Fence
Place of Origin	Hebei, China
Standard	AISI, ASTM, DIN, JIS, GB, EN
Surface Treatment	Galvanized and Black PVC-coated
Opening Size	25×25 mm, 40×40 mm, 50×50 mm, 100×100 mm (1″-4″)
Mesh Height	0.5 – 2.5 m or be customized
Length	30m, 50m, 100m/roll, customizable
Post	Round Post
Other Colors	Green, blue, white, yellow, gray, etc.
Function	Playground, stadium, basketball court, courtyard, airport, prison, swimming pool, villa, residential fence, Trellis & Gates
Recommended pairing	Barbed wire, razor barbed wire
Sample	Free Available
Payment term	TT 30% Advance + 70% Balance
Price Item	FOB, CIF, EXW, CFR, etc
Packing	Plastic Film + Metal Pallet
Certification	ISO 9001, SGS, ABS, BV
MOQ	240rolls, 5 tons

What is a black chain link fence?

Black chain-link fencing is a PVC-coated metal fence with a galvanized steel wire core coated with a black polyethylene (PE) or polyvinyl chloride (PVC) coating. This type of fencing is both corrosion-resistant, rust-resistant, and weather-resistant. Its simple, attractive black appearance makes it a popular choice for isolation and protection in residential areas, parks, sports fields, and other locations, ensuring both safety and environmental compatibility.

black chain link fence post

High Quality PVC Coated Chain Link Fence

Plastic coated black chain link grid

Features of Black chain link fence

1. Durability and corrosion resistance

Made of galvanized steel wire treated with PVC or powder coating, it has high corrosion resistance.

2. Wide field of vision

Transparent barrier. Chain link fencing is low maintenance and has a lifespan of 15 to 20 years.

3. Aesthetics

Black chain wire fencing is the most popular choice, and PVC-coated chain link fence also has a variety of color options.

4. Design flexibility

Black chain mesh fencing can be customized according to customer needs, including height, mesh size color, etc.

5. Economical

The black PVC coated chicken wire has a low manufacturing cost, and simple installation and maintenance.

6. Strong adaptability

Adapts to various terrains and climatic conditions, and can remain stable whether on flat land or hillside.

7. Wide range of uses

Black cyclone fencing has wide applications which include residential areas, commercial areas, industrial areas, sports venues, and zoos, etc.

6 black chain link fence

Zoo Fence

Black PVC Coated Chain Link Fence

Where are black chain link fences used?

1. Residential Areas and Private Gardens

Black is more decorative than traditional silver-gray and blends better with residential landscapes. It is commonly used for villa and garden fencing.

2. Public Parks and Gardens

Used for demarcating areas, protecting flower beds, or surrounding playgrounds; garden fencing, landscaping fencing, airport fencing, and hospital fencing.

3. Stadiums

Commonly used to enclose tennis courts, basketball courts, and soccer fields. The black background provides better visual contrast, making it easier for spectators to watch the game.

4. Commercial and Industrial Land

Used for perimeter fencing, separating equipment areas, and dividing logistics warehouses. The PVC coating provides enhanced corrosion resistance.

5. Schools

Fencing around campuses, playgrounds, and athletic fields provides security while creating a cleaner campus environment.

6. Transportation Infrastructure

Used for highway noise barriers, protective netting along railway lines, and around bridges. Black is stain-resistant and visually less obtrusive.

7. Temporary Security Fences

Used to demarcate areas and control crowd flow at construction sites or during temporary events such as concerts and celebrations.

8. Agriculture and animal husbandry

Orchard fencing or livestock fencing in grasslands, fields, farms, and pastures can prevent theft and facilitate management.

black chain link fence cost

Black chain link road guardrail

black chain link

FAQs

1. How far apart are black chain link fence posts?

Spacing is usually 4-10 feet and should not exceed 10 feet in the center. Because chain link fence posts are smaller and stronger than other types, the holes should be smaller and spaced farther apart.

2. Is black chain link fence more expensive?

It is cheaper than other types of fences, easier to maintain, and has a longer lifespan than most chain link fences, so many people choose it. However, compared to a galvanized steel chain link fence, the black galvanized chain link fence is a bit more expensive.

3. Which is better, a black or galvanized chain link?

The black galvanized fence is definitely better. It is better than galvanized chain link fence panels in terms of durability, cost-effectiveness, maintainability, corrosion resistance, color, and service life. Because there is an extra layer of black coating, it is equivalent to an extra layer of protection for the cyclone net. The only thing is that the price is higher than that of a galvanized steel chain link fence.

4. Does a black chain link fence fade?

It will not fade, chip, or peel, usually within 15-20 years. It will last about 5-10 years longer than a wooden fence of the same price. Over time, the vinyl coating will fall off, and the galvanized metal wire will be exposed to the air, continuing to provide use.

Pool safety fence

Residential Black Chain Link Fence

chain link fence black vinyl

Price of black chain link fence

$10 – $34 per foot average cost:

(1) $5 – $19 per foot material cost

(2) $5 – $15 per foot labor cost

$1,500 – $4,800 average cost to install a 150-foot fence

$10 – $34/ft² to install an 8-10-foot high black wire fence

By comparison, standard galvanized chain link fencing costs $9-30 per foot.

Costs at different heights

Fence Height	Price range, including materials and installation
3-4 feet high (small front yard fence)	$13 to $30 per foot
5-6 feet high (good for backyard and front yard)	$14 to $32 per foot
7-8 feet high (backyard fence)	$17 to $34 per foot
10 feet high (backyard tennis court/basketball court)	$19 to $38 per foot

Cost of different wire gauges

The common residential fence uses 9- or 10-gauge wire and mesh with a 2 or 2 3/8-inch diamond. This size provides enough strength and longevity for residential front and back yards. As we know, the smaller the gauge, the thicker the wire, so if you want to install a stronger fence, it is recommended to use 6-gauge wire mesh, which is commonly used for industrial and commercial fences, and the corresponding cost will be doubled.

Wire Gauge	Price range per linear foot (including materials and labor)
6	$15.50 to $37.80
8	$14.40 to $35.70
9	$13.50 to $33.10
11.5	$12.50 to $30.90

Airport Fence

Black PVC Coated Chain Link Fence

black chain link fence gate

Recommended mesh size for different purposes

The distance between the two wires of the diamond mesh is the opening size of the wire mesh. The smaller the opening, the stronger the fence and the higher the cost.

1. Residential fence: 2-inch or 2 ⅜-inch openings are commonly used, and the price per linear foot is $2.6-$11.7, depending on the height of the fence.

2. Pool fence, commercial facilities: Most of the diamond-shaped wire mesh is 1 ¼-inch, which can be supplied in 4-foot wide rolls, and the price per foot is $7.0 to $11.0.

3. Tennis courts, sports fields, and industrial projects: Use wire mesh with an opening of 1 ¾, which is mainly available in rolls of 10 to 12 feet wide, and the price per linear foot is $16 to $20.

Costs of different mesh sizes and heights

Linear Feet	4 feet tall	6 feet tall	8 feet tall
50	$ 500 – 1,350	$600-1,450	$ 650-1,600
100	$ 1,000 – 2,700	$1,200 – 2,900	$ 1,300 – 3,200
150	$ 1,500 – 4,000	$ 1,800 – 4,400	$ 1,950 – 4,800
200	$ 2,000 – 5,400	$ 2,400 – 5,800	$ 2,600 – 6,400
300	$ 3,000 – 8,100	$ 3,600 – 8,700	$ 3,900 – 9,600
400	$ 4,000 – 10,800	$ 4,800– 11,600	$ 5,200 – 12,800

Aluminum Chain Link Mesh

black chain link fence for sale

Chain link mesh passed quality inspection

Export Case

Green and Black PVC coated chainlink mesh expoted to Iran

396 rolls Green and Black PVC coated chainlink mesh expoted to Iran

Black Chain Link Fence For Sale – Wanzhi Steel

In short, choosing a black chain link fence means choosing superior weather resistance, understated aesthetics, and rugged security. If you’re looking for something more, we also recommend popular colors like dark green (perfect for a natural landscape) and dark gray (for a modern industrial look).

Why Choose Us?

(1) Intelligent Production Across the Entire Industry Chain

Combining wire drawing, mesh weaving, galvanizing, and PVC dipping and spraying, our fully automated CNC equipment ensures efficient control from raw materials to finished product.

(2) International Quality Certification

We implement ISO 9001 standards and are equipped with a mechanical laboratory and coating testers to thoroughly test raw material strength, plating, and coatings.

(3) Flexible Customization

We have a production base of over 1,000 square meters, an annual production capacity exceeding 400,000 tons, and ample inventory of standard specifications, enabling fast, high-volume delivery. We also offer flexible customization of non-standard sizes, wire diameters, mesh sizes, and colors.

(4) Core Process and Technology R&D

We master high-temperature hot-dip galvanizing and precision PVC dipping processes, ensuring product corrosion resistance and longevity. We continuously develop new fencing products with high corrosion and impact resistance.

Get samples or a bulk quote! Chat with Us Online,

or send an email to: info03@wanzhisteel.com.

Wanzhi Steel is an ISO 9001-certified steel factory located in Hebei, China. It has been specializing in the production of galvanized chain link mesh, cyclone mesh, Vinyl Coated Chain Link Fence, Galvanized Barbed Wire, PVC Coated Hardware Cloth, chain link fence posts, and PVC coated chain link fence for 14 years, with a monthly output of 1,800 tons. With high-quality products and good services, its products have been exported to more than 120 countries around the world.

Leave Us A Message

The galvanized chain link fencing is an important and common type of fence net. It has a silvery-white appearance, an interwoven diamond-shaped mesh, strong and flexible, and a long service life. It is the best material for isolation, protection, and safety in many fields. Wanzhi Steel is a formal and reputable supplier with multiple weaving machines. The wire diameter, hole diameter, height, and length are all customizable. You can Contact Us at any time for a free sample or a Free Quote!

gi chain link fence

chain link mesh

roll of chain link mesh

Galvanized Chain Link Fencing

Item	Galvanized Chain Link Fencing (Ring chain fence)
Place of origin	Hebei, China
Standard	AISI, EN, GB, ASTM, JIS
Transportation	15-18 days
Surface treatment	Hot dip galvanizing/Electro galvanizing
Coating options	PVC/Vinyl coated
Color	Black, green, silver, etc
Height	0.5m-3.0m
Length	10m-100m
Wire diameter	1.0-6.0mm
Mesh Size	20mm 40mm 50mm 60mm 80mm
Price Term	Ex-work, FOB, CIF, CFR, etc
Payment	T/T 30% Deposit
Transportaion	By sea
MOQ	5 Tons, 180 rolls

What is galvanized chain link fence?

The diamond chain link fence is galvanized to form a galvanized chain link fence. The zinc coating on the surface will prevent it from corrosion and rust, and the service life can be up to 15-20 years. It can be galvanized before or after weaving, which is much more durable than an ordinary chain link fence. To further extend its service life, you can consider a vinyl coated chain link fence, which extends its service life to 25-30 years.

Package of chain link fence mesh

1.5 Inch galvanized chain link mesh

0.5mm-2.5mm Supply Export Packaging

Key Features of Galvanized Chain Link Fencing

(1) Corrosion Resistance: The galvanized layer effectively blocks water and oxygen, providing strong rust resistance and long service life, making it suitable for humid and outdoor environments.
(2) High Strength: It can withstand certain impacts and tensile forces, providing excellent anti-theft and protective properties, making it suitable for use in fences, guardrails, and other applications.
(3) Easy Installation: The chain’s flexible structure allows for quick cutting and splicing to suit the site, resulting in efficient installation.
(4) Transparent Vision: The grid design provides unobstructed vision, balancing protection with lighting and views. It is commonly used in areas such as courtyards and playgrounds.
(5) Low Maintenance: The galvanized layer is rust-resistant, requiring less frequent maintenance, making it less of a hassle than ordinary iron chains.
(6) High Cost-Effective: It’s cheaper than stainless steel fencing and has a longer service life, resulting in a better overall cost-effectiveness.

Galvanized chain link fencing wire Chart

Wire diameter	Mesh opening (inch)	Size (tall × length)
6 gauge	2	42″ × 50′
9 gauge	2	42″ × 50′
10 gauge	2	42″ × 50′
11.5 gauge	2	42″ × 50′
12.5 gauge	2	42″ × 50′
6 gauge	2-3/8	42″ × 50′
9 gauge	2-3/8	42″ × 50′
10 gauge	2-3/8	42″ × 50′
11.5 gauge	2-3/8	42″ × 50′
12.5 gauge	2-3/8	42″ × 50′

Chain Link Fence Edge Shape

Galvanized Chain Link Fence Process

gi cyclone mesh production

Where is Galvanized Chain Link Fencing Used?

Residential Properties

Galvanized Chain Link Fencing secures yards with clear visibility, using shorter heights to avoid visual obstructions. It also creates safe pet enclosures, letting pets enjoy outdoor space freely.

Commercial and Industrial Sites

Taller versions enhance security for commercial properties, deterring unauthorized access. In industrial settings, they secure warehouses and factories, withstanding harsh conditions and heavy use.

Public and Recreational Areas

It marks boundaries in sports facilities like tennis courts, allowing spectator views. Parks and playgrounds use it to enclose safe spaces for children.

Construction Sites

It blocks unauthorized entry, preventing theft of materials/equipment and public accidents during projects.

Animal Enclosures

Beyond pet areas, it forms secure habitats in zoos and wildlife parks. Farmers also use it to fence livestock, offering a cost-effective solution.

Security and High-Risk Areas

Combined with barbed/razor wire, it provides high security for correctional facilities and military bases. Its transparency aids surveillance while blocking intruders.

Slope Protection and Erosion Control

It covers slopes to stabilize soil, preventing erosion and landslides, thus protecting infrastructure and property.

gi fencing net

galvanized steel chain link fence

black chain link fence post

How much does chain link fencing cost?

Material superiority

Compared to wooden fencing, plastic fencing, and wire mesh, galvanized chain link fencing is a more economical solution. Galvanizing enhances its resistance to rust and corrosion, thereby reducing long-term maintenance costs. In addition, its simple installation further reduces the overall cost. Despite its lower price, galvanized chain link fencing still provides excellent security and visibility, and durability. If you are looking to balance budget and quality, galvanized chain link fencing is a very suitable choice.

Chain link fencing price

Generally speaking, the cost per foot to install a chain link fence ranges from $10 to $20. For example, the cost of installing a 100-foot-long chain link fence ranges from $1,000 to $2,000. This includes the cost of materials and labor.

Cost Factors of Chain Link Fencing

1. Height and length of the fence: The longer and taller the fence, the higher the cost.

2. Type of chain link fence: galvanized, vinyl coated, etc.

3. Type of gate: Single gates are cheaper than double gates, and gates with automatic openers are more expensive.

4. Complexity of installation: If it is on uneven terrain or surrounded by obstacles, the installation cost will be higher.

5. Labor cost: Labor cost varies from region to region.

galvanized cyclone fence

black galvanized fence

Green PVC coated GI mesh shipped to Iran

7 Tips to Save Money on GI Chain Link Fencing

1. Choose a less expensive chain link mesh, such as galvanized mesh.

2. Ask about discounts for bulk orders or self-installing your fence.

3. Look for reputable suppliers with guaranteed product quality.

4. Flexible choice of fence height and style.

5. Install fences during the off-season. Contractors often offer discounts on labor during the off-season.

6. Choose an experienced and licensed contractor.

7. Choose simple doors, such as single doors without automatic openers.

If you are on a tight budget, you may want to install the chain link fence yourself, but if you have never done it before, it can be a challenging task. If you are not confident about doing it yourself, you can look for a professional contractor, but remember to get quotes from multiple contractors.

What is a Galvanized chain link fence post?

It is an important part of the chain link fence system. This fence post has a zinc coating on the surface, which helps to improve its corrosion resistance and durability. It is widely used in residential, commercial, industrial, agricultural, and sports facilities to define boundaries, protect property, isolate areas, or serve as a security barrier.

galvanized 3 8 chain

9ga chain link fence

Galvanized chain link fence post size

The size of galvanized chain link fence posts is not fixed. It is determined by the height, length, and number of post spacing of the chain link mesh. The general range is as follows. If you have any questions about the post size, please let us answer them for you.

1. Diameter: 20mm-100mm

2. Thickness: 0.8mm-2.5mm

3. Length: 4ft, 5ft, 6ft, etc., Wanzhi Steel accepts customization

4. Zinc coating: 200g/m², please let us know if you have special requirements.

How long will a galvanized chain link fence last?

With good installation and maintenance, and in a dry, clean environment, the galvanized chain link fence can last for 20 years. On the contrary, in a humid, heavily polluted environment, the fence will be more susceptible to damage, that is, premature rust, and the lifespan may be only a few years.

galvanized chain link

galvanized steel chain

What is galvanized chain link fencing fabric?

This is a mesh made of high-quality Galvanized Wire. It is woven into a diamond-shaped mesh by a weaving machine. It is also called diamond mesh. As well as Cyclone Fence. The galvanizing treatment is designed to improve the corrosion resistance and service life of the steel wire. The mesh is made of four cross-woven steel wires. The size of the mesh and the diameter of the steel wire can be customized according to needs.

What is a galvanized chain link fence gate?

It is a gate built of galvanized hook mesh. The structure is hook mesh + door frame + hardware.

1. Chain link fence: woven into a diamond pattern by galvanized steel wire. This mesh has strength, durability, and visibility.

2. Door frame: made of galvanized steel pipe or steel pipe, used to support the chain link fence for installation and fixation.

3. Hardware: hinges, locks, and other components for fixing. Made of galvanized steel.

galvanized fence gate

Sports Field Fence

It has excellent characteristics of corrosion resistance and durability, security, and flexibility, and can be equipped with door locks for additional protection. The zinc coating on the surface prevents rust and is extremely easy to maintain. Commonly used in gardens, parking lots, parks, sports fields, livestock pens, etc.

Galvanized Chain Link Fencing Supplier – Wanzhi Steel

1. Intimate pre-sales and after-sales service, free quotation.

2. Customized solutions, different solutions for different uses.

3. Bulk order discounts and factory-direct prices.

4. High-quality and qualified products, full tracking by the quality inspection department.

5. Timely delivery.

6. After-sales service, up to 1 year after sales.

Get samples or a bulk quote! Chat with Us Online,

or send an email to: info03@wanzhisteel.com

Wanzhi Steel is an ISO 9001-certified steel factory located in Hebei, China. It has been specializing in the production of GI chain link mesh, Black chain link mesh fence, Galvanized Wire Mesh Roll, Galvanized Square Mesh, Diamond mesh, and Cyclone Fence for 14 years, with a monthly output of 1,800 tons. With high-quality products and good services, its products have been exported to more than 120 countries around the world.

Leave Us A Message

Steel exports fell 10.41% month-on-month, and hot-rolled coils fell 22.7% month-on-month.

Chinese Steel FOB Price (Unit: USD/ton)

Varieties	Port	Price (USD/ton)	Month-on-month decrease (US dollars/ton)
Hot-rolled coils	Tianjin Port	458	-39
Cold-rolled coils	Tianjin Port	544	-24
Hot-dip galvanized coils	Tianjin Port	600	-22
Medium and thick plates	Tianjin Port	465	-31
Rebar	Zhangjiagang	475	-28
Wire rods	Zhangjiagang	475	-34

China’s Export Overview

In July 2024, the export volume of steel products was 7.83 million tons, a decrease of 10.41% from the previous month and an increase of 8.5% from the previous year. From January to July, the cumulative export volume was 61.23 million tons, an increase of 21.8% year-on-year. The import volume was 500,000 tons, a decrease of 12.28% from the previous month and a decrease of 25.6% year-on-year. From January to July, the cumulative import volume was 4.12 million tons, a decrease of 6.7% year-on-year. Overall, affected by the traditional off-season demand, the export volume continued to decline in July, the domestic supply and demand pressure was high, and the import volume continued to decline.

Export volume of major steel products in China (10,000 tons)

Types	July 2024	Month-on-month	January-July 2024	Year-on-year
Steel	782.7	-10.5%	6122.7	21.8%
Billet	35.2	13.8%	182.4	-5.6%
Rods and Steel wires	89.9	-13.9%	700.4	10.3%
Hot-rolled coils	152.2	-22.7%	1578.2	47.8%
Cold-rolled coils	62.3	-13.7%	460.2	22.6%
Medium and thick plates	74.6	-14.7%	555.5	14.6%
Coated plates	155.9	4.5%	1070.3	20.6%
Coated plates (strips)	59.6	-9.0%	416.1	16.2%
Angle profiles	41.0	5.3%	292.0	10.1%
Pipes	83.5	-12.6%	610.7	3.9%
Railway steel	8.3	28.5%	46.4	42.9%
Electrical steel plates (strips)	13.3	28.4%	83.0	22.6%
Others	42.1	-11.6%	309.9	16.6%

Top 10 destination markets for China’s finished steel exports (10,000 tons)

Country	July 2024	Month-on-month	Year-on-year
Vietnam	62.6	-27.3%	-2.2%
South Korea	53.1	-11.4%	-13.2%
Thailand	52.6	26.1%	77.4%
Philippines	41.3	-11.0%	9.4%
UAE	38.8	-1.9%	44.4%
Brazil	36.5	23.8%	34.5%
Indonesia	35.4	-12.5%	50.8%
India	29.1	-7.4%	0.5%
Saudi Arabia	28.7	-11.2%	37.2%
Türkiye	22.9	-45.3%	7.8%

In July 2024, China’s billet exports were 350,000 tons, up 13.76% from the previous month and 36.17% from the previous year. From January to July, China’s total billet exports were 1.82 million tons, down 110,000 tons from January to July last year, a decrease of 5.64%. Overall, China’s billet exports showed a steady upward trend.

The export value of Chinese billets per ton was US$500/ton, down US$53/ton from July last year, a decrease of 9.65%. Judging from the trend of China’s billet export value, in the past year, the export value of billets per ton has fluctuated in the range of US$500-580, and the price in July was the lowest in a year.

My WhatsApp: +86 13938459717（Click To Directly Chat）

My Email: info03@wanzhisteel.com (Click To Email Me )

Leave Us A Message

Galvanized Steel Mesh Panel is a longitudinal and transverse mesh panel made of galvanized wire welded together, which is not only more versatile, but also has excellent durability, corrosion resistance, and cheaper price, Wanzhi Steel is a professional supplier of Galvanized Steel Mesh Panels, with excellent quality and exported to many countries, we have a wide range of We have many sizes of mesh panels, and PVC coated GI wire meshs if you need, own factory in Anping County, Shandong Province, 10,000 square meters plant, plenty of stock, if you buy in bulk, we will offer direct selling price.

galfan coated welded wire mesh

Galvanised Square Mesh Panel

Hot dip galvanized welded wire mesh panel

Specification

Item	Galvanised steel mesh panels
Place of Origin	Hebei, China
Delivery Time	10-18 days
Standard	AISI, ASTM, DIN, JIS, GB, EN
Material	Q195/Q235 carbon wire, galvanized steel wire
Processing Service	Bending, Welding, Cutting, Punching
Surface Treatment	Hot dip Galvanized
Wire Diameter	0.5 mm – 6 mm
Hole Shape	Square or Rectangle
Hole size	1/4″ x 1/4″-6” x 8″
Height	Can be specified
Length	Can be specified
Color	Silver,
Sample	Free Available
Payment term	TT 30% Advance + 70% Balance
Price Item	FOB, CIF, EXW, CFR, etc
Packing	Standard export packaging
Certification	ISO 9001, SGS, ABS, BV
MOQ	200 pieces
Transportation	By sea, by land

What are the types of galvanized steel mesh panels?

It is welded mesh panels with both performance and aesthetics, the main types of common applications in life: concrete wire mesh, 3D fence panels, gabion cage, reinforced mesh, clear view fence, garden net, hardware cloth, galvanized cattle fence, hog panels, goat fence, horse panels, cow fence, black wire mesh fence, decorative wire mesh, galvanized netting, 6×6 welded wire, 1 4 welded wire mesh and other livestock fences.

Difference Between Welded and Woven Wire Mesh

Welded Wire Mesh

Welded Wire Mesh Panels

Galvanized mesh after welding

Key features of galvanized wire mesh

1. Corrosion resistance: The galvanized layer can effectively prevent the wire mesh panel from rusting and extend its service life.

2. High strength: The steel wire is firmly welded and can withstand large external impacts.

3. Flexibility: Different specifications and sizes can be customized according to specific needs, such as different apertures, mesh diameters and panel sizes.

4. Aesthetics: After galvanizing, the surface is bright and has a certain decorative effect.

Where is galvanized wire mesh used?

Construction field

Concrete reinforcement mesh can prevent cracking, plastering mesh is used for external wall insulation and crack resistance, and welded mesh is used for the ground and roof to prevent deformation.

Agriculture field

Poultry and livestock fences prevent escape and sky and earth invasion, orchard bird-proof nets can protect crops, and plant climbing nets can help growth and achieve efficient management.

Industry field

Mine support nets prevent collapse, equipment protection nets prevent damage, and are also used for storage and separation of materials to protect industrial production safety and efficiency.

Infrastructure field

It can be used for construction safety fences to demarcate areas, drainage filtration to prevent blockage, slope reinforcement to protect water and soil, and rockfall nets to prevent rolling stones.

Transportation and logistics field

Trucks are fixed to prevent displacement, roads are reinforced to stabilize the roadbed, and high-speed guardrails, billboard frames, to ensure safe and smooth transportation.

Welded mesh fencing and gates

square welded wire mesh

gabion retaining wall

What is the price of galvanized steel mesh panels?

The price range is from a few dollars to tens of dollars per sheet, depending on the size and quantity of the product. You can contact my WhatsApp for a free quote, or you can send me an email and list the product dimensions, such as wire diameter, aperture, stencil size, and packaging requirements. I will reply to you with an accurate quote within 8 hours.

What is the difference between GI steel mesh panel and PVC coated wire mesh?

Galvanized Steel Mesh Panel	VS	Pvc coated wire mesh
Low carbon steel wire galvanized	Material	High quality steel wire welding + coated with PVC or PE, PP
Strong corrosion resistance and easy maintenance	Characteristics	Strong corrosion resistance, weather resistance, flame retardant, anti-aging
Zinc layer anti-corrosion	Anti-corrosion method	PVC plastic coating for corrosion protection
Poultry cages, drainage troughs, rodent-proof nets, machinery covers	Application	Mostly used outdoors, such as stadium fences, greening protection nets
High cost performance	Price	Slightly more expensive than gi mesh

Galvanized welded wire mesh

Carbon steel Clearview Fence Panels

black galvanized fence

FAQ

Can I use welded wire mesh to install a shelf for my garage?

A1: Yes, but since it is not too rigid, you may want to use wooden or metal beams to support it from below or from the side.

Is welded wire mesh suitable for animal cages, including hamsters, birds, and rabbits?

Yes, the welded mesh is not only suitable for large livestock, but also for dogs or cats, and smaller hamsters, birds or rabbits. You need to choose a mesh with smaller mesh.

Is this product suitable for pond fencing?

Yes, it can be fixed to the fence posts of the pond and fixed with parts such as lashing wire to serve as a safety barrier.

Welded panel production

Mesh Panel Welding

square welded wire mesh

What mesh size do you recommend when building a small birdhouse?

For small birdhouses, a mesh size of 13mm x 13mm is the most suitable. Too large will be penetrated, and too small will affect the visual range.

Can I use welded wire mesh to protect windows?

Absolutely, with some kind of frame to reinforce the mesh, such as a wooden frame, and staples to fix the mesh.

How long does galvanized steel mesh last?

Steel with a galvanized coating thickness of 85 µm in a C2 environment will last between 30 to 50 years before maintenance is required. Steel with a galvanized coating thickness of 85 µm in a C4 environment — 20 to 40 years before maintenance is required.

Package & Shippment

The mesh panels are packed in bundles, which are bundled according to the weight required by the customer, wrapped with kraft paper and plastic film, and fixedly stacked on wooden pallets. You can specify the packaging.

98 tons of GI welded mesh shipped to Turkmenistan

98 tons of GI welded mesh to Turkmenistan

Welded Mesh Panel Packaging

Welded Mesh Package

GI Steel Mesh Panel Supplier- Wanzhi Steel

(1) Advanced production equipment: fully automated production line to ensure efficient and precise processing, modern hot-dip galvanizing process, uniform and firm zinc layer
(2) Strict quality control: equipped with professional laboratories, salt spray test/tensile test, etc., and implements ISO 9001 quality management system.
(3) Strong production capacity guarantee: 1000㎡ modern production bases, monthly production capacity of 50,000+ steel mesh plates.
(4) Professional technical team: continuous R&D and innovation, a 20-year industry experience engineer team.
(5) Global export: provide customized solutions, support non-standard customization, and OEM/ODM services. Fast delivery, 10-18 days.

Get samples or a bulk quote! Chat with Us Online,

or send an email to: info03@wanzhisteel.com

Wanzhi Steel is an ISO 9001-certified steel factory located in Hebei, China. It has been specializing in the production of SS steel wire mesh, Galvanized Diamond Mesh, Galvanized Steel Wire Mesh, GI expanded metal mesh, Crimped Wire Mesh, Insect screens, Gabion Basket, and Poultry Netting for 14 years, with a monthly output of 1,800 tons. With high-quality products and good services, its products have been exported to more than 120 countries around the world.

Leave Us A Message

Wire Mesh For Concrete Slab is made of low carbon steel wire, also known as welded wire mesh (WWF) or steel mesh, it consists of cross-welded steel wires and has good toughness and tensile strength. It is used in conjunction with concrete to prevent masonry cracking and is used in construction fields such as roads and buildings.

– Wire Gauge: BWG12-BWG24

– Length: 5m,10m,25m,30metc

– Height: 0.8 m- 2.4 m

– Transportation: By land, by sea

– MOQ: 5 tons

– Use: Building materials

Chat Online

Send Email

slab reinforcement mesh manufacture in China
wire mesh for concrete
Production of Mesh for Concrete

Wire Mesh For Concrete Slab Specification

Item	Wire Mesh For Concrete Slab(Plain Weave Welded Concrete Reinforcing Mesh)
Material	Q195, Q235 Low-Carbon Iron Wire, Galvanized Iron Wire, Black Wire Mesh
Type	Welded Mesh
Place of Origin	Hebei, China
Delivery Time	15-21 days
Processing Service	Bending, Welding, Decoiling, Cutting, Punching
Surface treatment	electro galvanized, hot dipped galvanzied, powder coated, Epoxy coated
Aperture	60150mm, 5075mm, 5050mm, 50100mm, 100*200mm, etc
Payment Term	FOB/CFR/CIF
Payment method	T/T 30% Prepayment

Types of wire mesh for concrete slabs

1. Welded wire mesh (WWM): The most common type, welded from cold-drawn steel wire. Wire gauge and mesh size can be customized.
2. Expanded metal mesh: Made from a single piece of steel cut and stretched into a diamond pattern. Has good strength and drainage properties.
3. Fiber mesh: Made from small randomly oriented fibers mixed into concrete. Has some crack resistance, but not as strong as wire mesh.

Concrete mesh-smooth round bar welding

reinforced concrete slab china factory

Welded concrete mesh

Benefits of Using Wire Mesh in Concrete Slabs

1. Added Strength: This heavy-duty 2×4 galvanized welded wire mesh panel is very durable and in addition to being resistant to cracking can be used for wildfowl coops and large dog kennels.
2. Customizable aperture: A variety of opening options are available, including 60x150mm, 50x75mm, 50x50mm, 50x100mm, and 100x200mm.
3. Multiple Finishes: Choose from galvanized, PVC coated, powder coated, and more.
4. Various sizes: Available in lengths of 5m-30m and heights of 0.8-2.4m, customizable.
5. Cost-effective: Compared with other reinforcement methods such as steel bars, wire mesh is relatively cheap and easy to install. It is a cheap alternative to steel mesh.
6. Conforms to international standards: Produced in accordance with ISO 9001:2015 standards, conforming to international quality standards, safe and reliable.

Wanzhi Wire mesh for concrete slab Cases

Reinforcing Mesh to Ethiopia

226 tons Reinforcing Mesh to Ethiopia

Wire mesh for concrete slab price

According to different applications, different steel diameters, corresponding to different prices, the following as a reference, can ask Wanzhi Steel for a quotation.

For example:

1. Mesh size: 100mm×100mm, 150mm×150mm, 200×200mm. Wire diameter: 5-10mm, mesh panel 2.2×5.8, 2.3mx5.9m,2.4mx6.0m. The price starts from $0.6/meter. Our price range at this stage is $10-45/pc.

2. 6 Gauge Concrete Wire Mesh is now available from $630/ton.

3. By the square, 0.25-0.38” wire diameter, 3 x 3cm mesh, lengths 5-30 meters, etc., prices start at $2/square.

Spider Chairs, Reinforcing Bar, and Mesh in Suspended Slabs are available for sale.

Can you use wire mesh in the concrete slab？

The answer is split into situations, depending on what you are using it for.

1. Simple projects

Wire mesh is acceptable for projects with low loads, such as single-story houses, ordinary parks, and simple shelters.

2. Lightweight, Minor Works

For projects with low structural requirements, such as residential driveways, sidewalks, or patios, wire mesh provides sufficient support to reinforce concrete slabs and walls. 10-gauge wire mesh is commonly used, as it strengthens the concrete during temperature fluctuations. 6-gauge wire mesh is also commonly used, but is heavier.

Concrete Pouring for Road Surfaces

reinforcement mesh for garage

concrete reinforcing mesh

3. Large, complex projects

Wire mesh is essential for bridges, airport runways, floor slabs, and more complex projects. It helps prevent horizontal or vertical separation after cracking, but it does not increase tensile strength or rigidity. Therefore, reinforcing steel bars are also necessary to increase rigidity and strength, but to prevent the structure from yielding due to overloading.

How to lay wire mesh for concrete？

Tools: Cutting tools for the steel and the wire, bar chairs, power lead, safety gear, measuring tape, and joining wire.

1. Excavate the ground, measure the length of the trench, level each flat surface, and lay bar chairs at about 1 meter intervals, symmetrically placed along the trench.

2. Cut the wire mesh to be cut, and tie the overlapping mesh with the joining wire first, covering a length of at least 500mm.

3. Then Pour concrete.

mesh cement

wire mesh for concrete

concrete mesh

FAQs

1. Should I put wire mesh in the concrete slab?

Larger projects in general, such as utility buildings, parking lots, viaducts, and airports definitely require the placement of reinforcing wire mesh in concrete slabs. Concrete slabs on their own are usually less than ideal, so the placement of wire mesh not only distributes the load weight evenly, holds the material together, provides support and extra strength in addition to helping to minimize cracking and settlement of the concrete slab. It is an essential step in construction work.

2. What gauge wire mesh for concrete slab?

The gauge of the wire mesh usually depends on the actual situation. Standard construction wire mesh applications are residential and light commercial concrete reinforcement. For light loads, 10 gauge wire mesh is sufficient; for higher loads you may need 8-gauge (D2.1), 6-gauge (D2.9), or 5-gauge.

3. What size is steel mesh for a concrete slab?

Standard reinforcing mesh panel size is 6.0 m x 2.4 m (holes: 150 mm x 150 mm), 1/8 inch (4 mm) thick. Trench mesh products are available in lengths of 6.0 meters and standard widths of 200-400 mm.

4. When to use wire mesh in concrete?

When your project is slightly more complex, or your building requires higher load bearing, simple concrete is not enough for the project, especially when the concrete shrinks and cracks as it dries. This is when the slab needs to be reinforced by embedding wire mesh or fiber mesh etc., in the wet soil. Secondly, proper soil compaction can also alleviate cracking due to uneven settlement.

Galvanized welded mesh shipped to India

Galvanized Concrete Mesh Production Line

Hot-dip Galvanized Welded Mesh Panel

5. Does wire mesh keep concrete from cracking?

Rebar cannot prevent concrete from cracking; its purpose is to strengthen the structure and slow the propagation of cracks. Concrete and rebar have different coefficients of thermal expansion, resulting in different elongations when subjected to stress. Their strength properties differ: concrete is strong in compression but weak in tension. Under thermal or mechanical stress, concrete cracks first, before the rebar takes effect. Just as when a concrete beam bends at the base, the rebar acts like a bungee cord, holding the structure together. Therefore, the bond between wire mesh and concrete is crucial and plays a significant role in construction.

6. What is the wire mesh in concrete called?

Welded or reinforcing mesh, available in rolls or sheets, usually galvanized. Reinforcing steel contributes to axial strain and cracking throughout the floor slab. Increases the tensile strength of the mesh.

7. Where should wire mesh be placed in concrete?

In the case of 4 – 6 inch thick residential slabs, the grid should be placed at mid-depth. It is difficult to place the grid in the upper third if you want to avoid the saw kerf and get a small amount of coverage. It is recommended that it be anchored in the center of the floor slab. The grid must be at least 5 cm above the compacted substrate and about 4 cm below the top of the slab. The most common methods of laying WWR are (1) Chair WWR, (1) Pouring concrete in two layers and placing WWR in the first layer.

Quality Inspection

Galvanized mesh after welding

Welded concrete mesh

Concrete Slab Wire Mesh For Sale – Wanzhi Steel

Wanzhi Steel Structure, as a high-quality supplier of concrete mesh panel, Welded Mesh panel, Reinforcing Steel mesh, accepts size customization, non-standard production and third-party quality inspection.

About Wanzhi Steel

✅ Focused on professionalism: Fully automated CNC production, welding stability ≥ 99.8%, mesh flatness tolerance < 2mm.
✅ High-quality materials: Q195/Q235 low-carbon steel wire, hot-dip galvanized ≥ 60g/m², corrosion and rust resistance for over 20 years.
✅ Customizable to all specifications: Mesh size 50-300mm, wire diameter 2-8mm, sizes 1×2m to 6×20m, with a design turnaround within 48 hours.
✅ Certification Guarantee: ISO 9001 and CE certified, each batch includes a quality inspection report, and a defect rate of <0.5%.
✅ Global Supply: Supports EXW/FOB/CIF, 24-hour after-sales response, factory direct price.

Get samples or a bulk quote! Chat with Us Online,

or send an email to: info03@wanzhisteel.com.

Wanzhi Steel is an ISO 9001-certified steel factory located in Hebei, China. It has been specializing in the production of high-quality rebar coil, ribbed bar, welded rebar mesh sheet, Galvanized Concrete Mesh, Galvanized Steel Stucco Netting, and Diamond Mesh Lath for 14 years, with a monthly output of 1,800 tons. With high-quality products and good services, its products have been exported to more than 120 countries around the world.

Leave Us A Message

If you need a piece of Concrete mesh but don’t know what size to choose to ensure it stays strong for decades to come, please refer to the table below. Wanzhi Steel – Woven and Welded Wire Mesh Supplier, if there is a special need or you want a quote, please send us your request.

What are the types, sizes, and weights of Mesh reinforcing?

Specifically, it is categorized into standard mesh fabric (square mesh fabric), structured mesh fabric, long mesh fabric (fly end mesh fabric), and Wrapping mesh fabric.

CHART NO.1

Type	Mesh sizes				Cross sect area per		Nominal Weight	Sheets per	Sheets Weight
	nominal pitch of wires		Wire Sizes		metre width		MP	tonne
	main mm	cross mm	main mm	cross mm	main mm2	cross mm2	kg
1. Square mesh fabric
A393	200	200	10	10	393	393	6.16	14	70.96
A252	200	200	8	8	252	252	3.95	22.0	45.50
A193	200	200	7	7	193	193	3.02	28.7	34.79
A142	200	200	6	6	142	142	2.22	39.1	25.57

a193 wire mesh

concrete mesh

a393 wire mesh Factory

CHART NO.2

Type	Mesh sizes				Cross sect area per		Nominal Weight	Sheets per	Sheets Weight
	nominal pitch of wires		Wire Sizes		metre width		MP	tonne
	main mm	cross mm	main mm	cross mm	main mm2	cross mm2	kg
2. Structural mesh fabric
B1131	100	200	12	8	1131	252	10.90	8.0	125.57
B785	100	200	10	8	785	252	8.14	10.7	93.57
B503	100	200	8	8	503	252	5.93	14.6	68.31
B385	100	200	7	7	385	193	4.53	19.2	52.19
B283	100	200	6	7	283	193	3.73	23.3	42.97
B196	100	200	5	7	196	193	3.05	28.5	35.14

concrete reinforcing mesh

mesh cement

CHART NO.3

Type	Mesh sizes				Cross sect area per		Nominal Weight	Sheets per	Sheets Weight
	the nominal pitch of wires		Wire Sizes		meter width		MP	tonne
	main mm	cross mm	main mm	cross mm	main mm2	cross mm2	kg
3. Long mesh fabric
C785	100	400	10	6	785	71	6.72	12.9	77.41
C636	100	400	9	6	636	71	5.55	15.6	63.94
C503	100	400	8	6	503	71	4.51	19.2	51.96
C385	100	400	7	6	385	71	3.58	24.2	41.24
C283	100	400	6	6	283	71	2.78	31.2	32.03

steel mesh for concrete

wire mesh and concrete

mesh reinforcing sizes

CHART NO.4

Type	Mesh sizes				Cross sect area per		Nominal Weight	Sheets per	Sheets Weight
	nominal pitch of wires		Wire Sizes		metre width		MP	tonne
	main mm	cross mm	main mm	cross mm	main mm2	cross mm2	kg
4. Wrapping mesh fabric
D49	100	100	2.5	2.5	49	49	0.77	112.7	8.87

Features and uses of various types of concrete mesh

Popular sizes are a393, a142, a252, a193, and d49 as well as many others.
1. D49 Wire Mesh
D49 ‘wrapping’ concrete mesh, which is primarily for screed reinforcement due to its lightweight (100mm x 100mm aperture) construction.
2. A142 Mesh（6mm wires）
We have A142 rebar mesh, which is the lightest gauge ‘A’ spec concrete reinforcement mesh you can get, with 6mm steel rebar and 200mm x 200mm apertures. Commonly used for 100mm thick light use panels such as pathways, driveways, and garage bases.
3. A193 Mesh
Slightly larger diameter welded mesh, welded with 7mm rebar. It is suitable for both trails and driveways as well as heavier boards. In light-use applications, a single layer of fabric may be used, but in heavier jobs, two layers are used “top and bottom”
4. A252 & A393 Mesh
Both types of reinforcing mesh are of a higher specification and are commonly used for heavier 150-200mm thick slabs. Both are suitable for medium use, single or double layered (using rebar spacers), and are mostly used in driveways and extension areas (sometimes in conjunction with foundation reinforcement cages).

wire mesh for concrete

Modeling frame reinforcement

A193 HRB400 concrete welded wire mesh panel

5. B385-B503-B785-B1131
Type B Reinforcing Mesh is mainly used as a fabric for reinforcing concrete slabs, walls, and other structures. Type B Reinforcing Mesh, also known as structural mesh, consists of 10mm lengths welded to 8mm cross bars. Manufactured to BS4449 / 2005 standards, they are certified products and fully CE marked.
6. Flying end mesh
Benefits of flying end mesh: Accurate coverage, shorter laying cycles, less waste, more flexibility, and lower costs. Flying Ends are areas at the edge of a sheet of mesh reinforcement that only have bars oriented in one direction.

What size reinforcing mesh do I need?

The dimensions mentioned here refer to the diameter of the reinforcement, as for the area you can calculate it yourself (we can cut the mesh on request if needed), for smaller loads, such as passages, it is not necessary to use a reinforcing mesh, proper concrete is enough.

What are the dimensions of the grid for the driveway?

Concrete driveways for general use carry up to large SUV sized vehicles, which would only require one layer of A193 reinforcing mesh. However, if you wish to carry larger vehicles when they are in close proximity or several vehicles, then the A252 specification is required.

What size wire mesh is appropriate for my garage?

For an average home garage, 2 layers of A252 are excessive, usually for loads up to 4000kg, only the lowest specification A193 mesh is needed, but it is better to add an extra layer of reinforcing mesh, properly spaced, or just use a layer of a higher grade of reinforcing mesh, such as A252 reinforcing mesh fabric. It is best to consult a professional; you are welcome to contact us.

Production Line

a393 reinforcing mesh Manufacturer

Brazilian distributor orders delivery

Buy all sizes of Concrete Wire Mesh from Wanzhi Steel

At Wanzhi Steel, we offer a wide range of mesh sizes, including A142, A193, A252, A393, D49, and even B-size structural mesh (B503, B785, B1131). We stock all types of meshes (standard and commercial sizes) in large quantities, and we also offer customized rebar cutting and bending services, as well as the prefabrication of steel cages, columns, walls, and floor beams. Avoid middlemen and order directly from Chinese factory suppliers.

Get samples or a bulk quote! Chat with Us Online,

or send an email to: info03@wanzhisteel.com

Wanzhi Steel is an ISO 9001-certified steel factory located in Hebei, China. It has been specializing in the production of Steel Reinforcement Bar, deformed steel bar, Wire Mesh For Concrete Slab, Construction Binding Wire, Steel Reinforcement Mesh, Galvanized Concrete Mesh, GI Steel Stucco Netting, GI Welded Wire Mesh, and A193 Mesh for 14 years, with a monthly output of 1,800 tons. With high-quality products and good services, its products have been exported to more than 120 countries around the world.

Leave Us A Message

(hereinafter referred to as “Qingdao Port”), a busy scene – more than 200 routes converge here, and 20,000 TEU ships come and go freely.

August 29, 2024, Shandong Port Group Qingdao Port Qianwan Container Terminal, container ships berthing in an orderly manner, container loading and unloading efficiently, port throughput a busy. This year, Qingdao Port Qianwan Container Terminal container business to improve the quality and efficiency, a steady rise, the port attraction is getting stronger and stronger.

automated track

Efficiency Improvement

Global container blockage

As early as June 28, 2024, the Ministry of Transportation and Communications released the January-May 2024 port cargo, container throughput data, Shandong port of Qingdao Port completed 298.16 million tons of cargo throughput, an increase of 5.3% year-on-year, the container volume increased by 9.6% year-on-year. A set of figures, highlighting the development of Shandong Port Qingdao port resilience.

Recent Port News

On September 8, 2024, the Qianwan Container Terminal of Qingdao Port, Shandong Port, still has ships coming and going, and this comprehensive port area, which can berth the world’s largest container ships, maintains a busy scene. The Port of Qingdao is doing its best to advance and compete for first place in high-quality development. Nowadays, more than 200 routes are connected to the world, reaching more than 700 ports in more than 180 countries and regions around the world, and the density of routes ranks first among the ports in northern China.

Phase III automation project

Port Newscast

Surpassed 1.7 billion tons

Automation track of the third phase of the terminal

In Qingdao Port Automated Terminal Phase III, big ships gather in the harbor, and many automated rail cranes keep moving around in the yard, placing containers on the container trucks. The production tasks of the whole terminal are assigned and dispatched by A-TOS (Intelligent Production Control System), the intelligent brain of the automated terminal. The first nationally produced fully autonomous automated terminal is another shining business card of Qingdao Port to cultivate new quality productivity, which not only represents the advanced level of intelligence but also the embodiment of green development. These automated rail cranes have another identity – hydrogen-electric coupled DC-powered rail cranes.

Shining card of Qingdao Port’s productivity

“The hydrogen rail cranes in the third phase of the automated terminal use DC power supply, removing the cables on the traditional rail cranes, reducing the weight of each unit by about 10 tons, and reducing energy consumption by about 4%.” Zhang Changjiang, secretary of Shandong Port Qingdao Port’s fully automated container terminal’s Mission Committee and supervisor of automatic guided vehicles in the Engineering and Technology Department, said.

Zhongshan port is also clogged

Ship ready to berth

Zhang Changjiang said that the third phase of the automated terminal is in the process of optimization, and further improvements are being made from the single machine to the system in order to improve the productivity of the terminal. The future goal is to break through the “last kilometer” of automated terminal innovation, realize the high-level automation of shore-side loading and unloading equipment, and make the terminal more and more “smart”.

(Source: Shandong Port)

Want to know the steel wire and mesh Prices?

Get samples or a bulk quote! Chat with Us Online,

or send an email to: info03@wanzhisteel.com

Wanzhi Steel is an ISO 9001-certified steel factory located in Hebei, China. It has been specializing in the production of galvanized wire, SS wire, low carbon wire, spring wire, PVC Coated Galvanized wire, Cold drawn wire, GI stitching wire, Baling Wire, and high tensile wire for 14 years, with a monthly output of 1,800 tons. With high-quality products and good services, its products have been exported to more than 120 countries around the world.

Leave Us A Message

Recently, the steel grating produced by Wanzhi Steel has arrived at the customer’s designated port. This is our sixth cooperative customer.
The customer emphasized that the steel grating must be galvanized three times. So we strictly follow the customer’s requirements and track the quality throughout the process. Finally, we successfully completed the qualified high-quality galvanized steel grating.

Wanzhi Steel Group

Wan Zhi Technical Department

Workshop group photo

Why is the steel grating galvanized?

Because the customer said that their use environment is relatively strict, galvanizing is an economical and efficient method. If it is not galvanized, it may be easily corroded, so galvanizing is required. After galvanizing, the PH is PH6-PH12. Because the frequency of use is extremely high, the customer hopes to galvanize three times. In an industrial environment, the life of the hot-dip galvanized steel grating can also reach 20-30 years. In addition, the surface of the galvanized steel grating is not only beautiful but also exquisite.

bar grating

sink bottom grid

expanded steel grating

Yemen Client Background

The client has his own sales channels in the local area. He mainly sells steel gratings, including trench covers and pedals. His main sales groups are government agencies, campuses, factories, enterprises, and institutions. The client directly stated his use and concerns, and our communication was very smooth. He confirmed the cooperation on the same day after the quotation, which was beyond our expectations. We are honored that the client trusts us so much, and we did not disappoint the client’s trust. He said that he would continue to cooperate in the future, so we had our second, third, and now sixth cooperation.

steel grating

floor grating

Wanzhi Steel-Yemen Project Production Process

1. Machine pressure welding: Use high-voltage pressure welding machine for welding

2. The tooth size strictly meets the size, and there must be no less than 5 teeth per 100mm.

3. The length of the edge weld is not less than 4 times the thickness of the load flat steel

4. When the edge plate does not bear the load: it is allowed to weld 4 load flat steels at intervals, with a spacing of ≤180mm;

5. When the edge plate bears the load, the edge plate and the load flat steel should be fully welded, and interval welding is not allowed.

expanded metal grating

steel bar grating

metal grating

Yemen project inspection by Wanzhi QC department

Steel Grating Length Inspection

Thickness test of steel grating plate

Thickness test of mental sheet

Wanzhi Steel Packaging of GI steel grating – Yemen Project

About the packaging, there are generally three packaging methods:
1. Packing tape bundling, generally applicable to the more neat steel grating;
2. Screw rod fixing, using 4 screw rods passed through the aperture of the steel grating, with screws to lock the guarantee method;
3. Pallet guarantee, generally for export crating. Yemeni customers are packed on pallets.
Mainly according to the customer’s situation, if the goods are not much, and do not need to use a forklift loading and unloading, general bulk loading is more convenient. On the contrary, more goods, forklift loading, and unloading of the general packing will be more convenient, in short, all to the convenience of the customer, to protect the product during transportation does not produce cargo damage as a guideline.

galvanized steel grating

steel grating for sale

metal grating floor

Wanzhi Steel Wire and Mesh Factory

Galvanized wire for sale

annealed wire supplier

PVC mesh

Case Summary

This cooperation has deepened the familiarity of our Yemeni clients and strengthened the trust between the two sides. We hope our cooperation will be long and smooth. Wanzhi will not forget the original intention and will deliver satisfactorily repeatedly.

Wanzhi has a factory in Boxing County, Shandong Province. It is a professional wire mesh supplier and mainly deals in GI Wire, Rebar, PVC coated wire, construction tying wire, as well as Steel Reinforcement Mesh, Gi Concrete Mesh, and other mesh products.

If you are interested in galvanized grating sheets, welcome to contact Wanzhi Steel for details.

This is our website: https://wanzhifence.com/

WhatsApp: +8613938459717

Email: info03@wanzhisteel.com

Hot spot tracking

Leave Us A Message

WhatsApp

WhatsApp

E-mail

E-mail

Tel

Tel

Online

Top

Specification

What is a black chain link fence?

Features of Black chain link fence

1. Durability and corrosion resistance

2. Wide field of vision

3. Aesthetics

4. Design flexibility

5. Economical

6. Strong adaptability

7. Wide range of uses

Where are black chain link fences used?

1. Residential Areas and Private Gardens

2. Public Parks and Gardens

3. Stadiums

4. Commercial and Industrial Land

5. Schools

6. Transportation Infrastructure

7. Temporary Security Fences

8. Agriculture and animal husbandry

FAQs

1. How far apart are black chain link fence posts?

2. Is black chain link fence more expensive?

3. Which is better, a black or galvanized chain link?

4. Does a black chain link fence fade?

Price of black chain link fence

Costs at different heights

Cost of different wire gauges

Recommended mesh size for different purposes

Export Case

Black Chain Link Fence For Sale – Wanzhi Steel

Why Choose Us?

Leave Us A Message

Galvanized Chain Link Fencing

What is galvanized chain link fence?

Key Features of Galvanized Chain Link Fencing

Where is Galvanized Chain Link Fencing Used?

Residential Properties

Commercial and Industrial Sites

Public and Recreational Areas

Construction Sites

Animal Enclosures

Security and High-Risk Areas

Slope Protection and Erosion Control

How much does chain link fencing cost?

Material superiority

Chain link fencing price

Cost Factors of Chain Link Fencing

7 Tips to Save Money on GI Chain Link Fencing

What is a Galvanized chain link fence post?

Galvanized chain link fence post size

How long will a galvanized chain link fence last?

What is galvanized chain link fencing fabric?

What is a galvanized chain link fence gate?

Galvanized Chain Link Fencing Supplier – Wanzhi Steel

Leave Us A Message

China’s Export Overview

Export volume of major steel products in China (10,000 tons)

Top 10 destination markets for China’s finished steel exports (10,000 tons)

Leave Us A Message

Specification

What are the types of galvanized steel mesh panels?

Key features of galvanized wire mesh

Where is galvanized wire mesh used?

Construction field

Agriculture field

Industry field

Infrastructure field

Transportation and logistics field

What is the price of galvanized steel mesh panels?

What is the difference between GI steel mesh panel and PVC coated wire mesh?
